The lifting and lowering of the filter trough is crucial for the discharge of wheat grains. The usual chopper lift is automatically controlled by the cylinder or electric screw at the bottom of the filter tank, but in some specific equipment installation spaces. Due to the installation space, especially the installation height, the cultivating knife lifting screw or cylinder can not be properly installed, it needs to be changed to the self-developed cultivating knife manual lifting mechanism. The cultivating knife manual lifting mechanism is usually installed on the top of the filter tank. The knife rotation motor also uses a horizontal motor, which can further reduce the installation height and facilitate equipment installation and production operation control.
Mash/kettle/whirlpool tun + lauter tun
1 When the wort is filtered, only suction filtration can be used (ie, the sputum is in the filter tank, the wort is pumped through the wort pump, and the mashing/boiling pot is driven). The filtration speed is relatively slow, and the winemaker has higher requirements. Mistakes, lightly lead to tight wheat grain, difficult to filter, heavy will cause the sieve plate deformation, affecting subsequent use.
2 Such equipment is generally equipped with a stirrer in the mashing/boiling pot. Because the saccharification/boiling pot has the function of a swirling tank, the stirrer will affect the spin-drying effect.
3 Washing water can only be prepared in advance, stored in large basins, buckets or fermenters (generally not recommended to be stored in the fermenter, such as improper operation, easy to create a vacuum in the fermenter or affect the operation of the ice water system), operation Trouble, high heat loss.
4 Generally, only two batches can be brewed per day, and the brewmaster needs to work overtime.
The chiller must choose a large brand that is stable in quality and used.
The size of the ice water tank should be reasonably configured. It is recommended to have 2 refrigerators and two ice water coils. The two chillers work at the same time, reducing the burden on the chiller, one has a problem, and the other can operate normally.
