Dry control and sewage discharge After the washing is finished, the sewage valve is automatically opened to control the excess water in the pipeline and the wheat grains. When the time is up, the sewage valve is automatically closed.
Start-up, unloading, and closing the machine. When the sewage discharge is over, the hydraulic system is started, the filter press is turned on, and after the pressure plate is in place, the pull plate trolley starts to pull the plate. After each plate is fully opened, the hydraulic system is started and the filter plate is compacted.
Filter press CIP cleaning
Alkali washing
Pour the hot alkali in the alkali tank into the saccharification pot with a concentration of 2-3%. The temperature is heated to 60-70 ° C in advance, and the quantity is about twice the volume of the filter press.
After the alkaline washing program starts, the exhaust valve on the top of the filter press opens automatically and the lower feed valve opens automatically. When a material is detected before the pump, the pump is automatically started (the flow of the pump is in advance) (Setting), start to enter the caustic soda into the filter press from the bottom. When a material is detected at the top of the filter press, it means that the material in the filter press is full. At this time, the exhaust valve at the top of the filter press closes automatically.
When the material in the filter press is full, the upper feeding valve opens automatically, and the caustic soda is fed from the upper and lower parts of the filter at the same time. The balance tank circulates. When the circulation time is up, the return valve is automatically closed.
When the return valve closes automatically, start to flush the balance tank. Then flush each line separately, and finally drain the lye to a temporary storage tank or a boiling pot.
Pickling
The pickling procedure is the same as the alkaline washing procedure. (Generally not needed)
washing
Heat the water in the hot water tank to the specified temperature, the quantity is about twice the volume of the filter press.
After the water washing program starts, the exhaust valve on the top of the filter press automatically opens, the four water inlet valves automatically open, the hot water pump starts automatically (the flow rate of the hot water pump is set in advance), and the hot water is started to enter the filter When a material is detected at the top of the filter press, it means that the material in the filter is full, and at this time, the exhaust valve at the top of the filter is automatically closed.
