150 gallon stainless steel conical fermenter 250 gallon brewing system WEMAC Y041
Beer fermentation tanks are usually called CCT(Cylindrical Conical Tanks), FV(Fermentation Vessel) and FT,
primary fermentor or unitanks menas they are used both for fermenting and lagering.
Fermenting is the process during which the yeast transform the wort into beer.
Lagerings takes place after fermenting and is the time given to the beer to make them stabilize and age after the fermenting.
WEMAC Fermenter Basic Configuration:
The design pressure is 45 psi (3bar); working pressure is 15psi (1bar)
Four stainless steel legs with leveling footpads
Interior shell: 304 stainless steel, thickness 3mm
Exterior shell: 304 stainless steel, thickness 2mm
Interior and exterior finish bright polish to 0.6~0.8, very hygiene surface
60 degree cone bottom, also other angles can be specified during the design process
Combined drain extensions and beer port in cone are standard equipped
20%-25% head space, unless a different volume is requested
Top manway or side manway door for your choice
Polyurethane insulation thickness 80mm or 100mm for cooling jacket on side and bottom
WEMAC stainless steel fermenters can be individually temperature controlled through glycol jackets.
And they are mostly equipped with accessories, such as over pressure and under pressure valve, CIP cleaning port,
sanitary sample valve, manhole and so on. The design of WEMAC fermentation tanks is based on our vast beer knowledge.
Especially the conical fermenter bottom and the fact that we combine the fermentation and maturation in the same vessel.
In calculating the capacity and configuration of the fermentation and storage of beer,
sufficient time must be considered for fermentation and storage of the beer to produce good quality beer.
1) Automatic /semi-automatic operation system ,only need one or two brewer to operate.
2) With our equipment you can make different type of beer such as ale,lager, IPA, stout beer and so on,
we supply the brewing recipes free for our clients.
3) We have different capacity fermentation tank from 50L to 10000L per batch,
our brewery equipment approved Pessure CE, ISO ,and UL certificate.
4) We have got very good feedback from our clients。
5) Installation/Operation/ Service/ Maintenance Manual: All provided in English.
