300L Complete microbrewery system microbrewery equipment manufacturers WEMAC Y015
WEMAC 300L brewery equipment,very popular in the pub,resturant and lab.
Our whole equipment,2B surface inside, pickling passivation treatment, fine treatment of welding seam, no deformation; external surface drawing treatment,
beautiful appearance of equipment, piping layout, opening position, etc. to meet the requirements of operation, on-site installation and visit.
The inner material is SUS304, 3mm, and the outer material is 2mm;
The dimensions are D=960mm, H=2516mm.
Electric heating; heating to meet the temperature rise of 1-1.5 degrees / minute. Electric heating tube 6kw415V50Hz*4.
Thermal insulation rock wool, insulation laminate thickness of 80mm.
More than 40% of the air capacity.
The speed of the stirring motor is 19r/min. The material of the stirrer in the tank is stainless steel 304.
The lower part of the stirring shaft is supported by a bushing, and the shaft is marked with a scale.
The upper part of the pot has a seal to prevent steam from leaking from the shaft.
The upper steam discharge pipe has a diameter of 159, and a condensate collecting device is added to the steam discharge pipe,
and the drain pipe is embedded in the heat preservation layer.
About our 300L fermentation tank:
Inner material SUS304, thickness 3mm; outer material SUS304, thickness 2mm;
Outer dimensions: D=960mm, H=2400mm/device manhole opening height 2630mm.
Miller plate jacket, material SUS304, thickness 1.5mm, cylinder cooling area is about 40% of the surface area of the cylinder,
the cone cooling area is about 50%.
Polyurethane foam insulation, thickness 80mm.
The tank body pressure 2.5bar.
60 ° cone compression design.
Empty capacity 20%. The upper part of the tank cylinder is flush with the bottom of the washing ball.
With a ball washing, the installation position is slightly lower than the barrel and head weld, cleaning tube Ø32.
Internal roughness ≤ 0.4um, and no deformation, no scratches, weld 2B surface.
The upper part is installed with manhole and positive and negative pressure safety valve, single head.
Tank with temperature sensing, integrated outlet, waterproof grade IP67, sampling valve; bottom has a sewage outlet .
At the bottom of the cone, there is a hop-dried DN100.
The bottom sewage pipe Ø38.
WEMAC 300L brewery equipment,we adopt fermentation automation.
It's imported brand PLC and 10-inch large-screen touch screen joint control.
If you want to ask anything just fill in the form below and send us.
